SPECIFICATIONS |
|
Solution Tank |
5 Gallon |
| Recovery
Tank |
4 Gallon |
|
Solution Pressure |
50/100 PSI |
| Vacuum Motors |
Dual high
performance 2-stage and 3-stage |
|
Optional Heater |
1200 Watts, stainless steel |
|
Water Lift |
136" |
| Tank
Construction |
Polyethylene |
|
Baseplate |
Aluminum |
| Rear Wheels |
7 inches,
non-marking |
|
Casters |
2.5 inches |
| Power Cord |
25 ft.
detachable |
|
Hose Assembly |
15 ft. |
| Wand |
Deluxe
dual-jet S-bend stainless steel |
|
Dimensions |
28"H x 24.5"L x 16"W |
|
Weight |
57 lbs. |
|
Shipping
Weight |
65 lbs. |
|
Ship Dimensions |
25" x 17" x
29" |
|
* For units with heat, add 14
lbs. to ship weight. |
|
|
|
|
WARRANTY |
|
6 years on tank, 1 year on parts |
|
|
FEATURES |
 |
External heater is a snap to remove and keeps heat away from
the inside of the machine for longer life. |
|
|
"No drip" motor cavity guarantees water spilled on outside
of machine stays out! |
|
|
Silencer system for quieter operation. |
|
|
Upright-mounted motors along with a special intercooler
guarantee long life and durability. |
|
|
Standard
5-gallon bucket fits under drain valve for easy emptying. |
|
|
Opens
quickly like a "clamshell" for easy servicing. |
|
|
Full complement of optional accessories attaches to the back
of unit for cleaning upholstery, stairs, etc. |
|
|
Handle folds down for easy transport and compact storage.
|
|
|
Optional heating system delivers consistent 170 degrees.
|
|
OPTIONAL ACCESSORIES |
| 1204AC/1204ACH |
Powermate -
12" wide power brush |
| B00216 |
Power cord for Powermate |
| 330ACS |
10"
Stainless Steel Wand |
| 1038AC |
Crevice Tool |
| 1039AC |
Stainless Steel Upholstery Tool |
| 323AC/323ACH |
Prespray Wand
|
|
MODELS |
| All
models come complete with a 15-foot hose assembly. |
| 500AX |
Single 3-stage vac, 136" lift, 50 psi |
| 500BX |
Single 3-stage vac, 136" lift, 100 psi |
| 500BX-EH |
Single 3-stage vac, 136" lift, 100 psi w/tank heater |
|
